Detailed specifications

1. Applicable PCB thickness: 1.60mm

2. Terminal passable current value: 12A/core (within 30 degrees Celsius)

3. The selection of direction and design supports multiple applications

4. The larger guiding design facilitates insertion

5. Number of cores: 04 to 100 even-numbered pins (complete range of models)

6. The reliable contact structure can make the contact more stable and reduce the impedance

7. The plastic can withstand a temperature of 270 degrees

8. Connection method: straight, through-hole, SMT

9. Contact finish : Gold plating

10. Plastic material: PA9T

11. Production cycle: 2-3 weeks

12. Packaging method: Tray packaging
