Detailed Specifications

1. Connection method: Horizontal, vertical, side insertion

2. Current capacity for power pins : 60A/pin *6 groups

3. Current capacity for signal pins : 3A/pin , 2.54mm pitch

4. Signal pins combination options : 2*1~2*12 pins

5. The larger guiding design facilitates the fit

6. The unique cooling design ensures that the temperature rise does not exceed 30 degrees

7. The recommended thickness of the gold fingers PCB is 1.60mm

8. Contact finish : Gold plating

9. Plastic material: LCP

10. Production cycle: 15-20 days

11. Packaging method: Tray packaging
